Explore Our Crimped Wire Mesh
Crimped Wire Mesh
Pre-crimping wire enables the mesh to lock together, creating a tight weave with good rigidity and pleasing aesthetics. It is used extensively in architectural applications, as infill panels, cages and decoration. It is also used in acoustics, filtration, bridge guards, aerospace parts, rodent control, and truck grills
Pre-crimping wire enables the mesh to lock together, creating a tight
weave with good rigidity and pleasing aesthetics. It is used extensively in architectural applications, as infll panels, cages and decoration. It is also used in acoustics, fltration, bridge guards, aerospace parts, rodent
control, and truck grills.
| Inch Mesh | Wire Diameter | Open Area | Weight | ||
|---|---|---|---|---|---|
| inches | mm | % | Lbs/sq. ft. | Kg/m2 | |
| 1 | 0.120 | 3.048 | 77.44 | 0.929 | 4.536 |
| 1 | 0.135 | 3.429 | 74.82 | 1.178 | 5.752 |
| 1 | 0.187 | 4.750 | 66.10 | 2.278 | 11.122 |
| 1 | 0.250 | 6.350 | 56.25 | 4.124 | 20.135 |
| 1.5 | 0.120 | 3.048 | 84.64 | 0.781 | 3.813 |
| 1.5 | 0.135 | 3.429 | 82.81 | 1.178 | 5.752 |
| 1.5 | 0.187 | 4.750 | 76.62 | 2.278 | 11.122 |
| 1.5 | 0.250 | 6.350 | 69.44 | 4.124 | 20.135 |
| 2 | 0.120 | 3.048 | 88.36 | 0.462 | 2.256 |
| 2 | 0.135 | 3.429 | 86.96 | 0.585 | 2.856 |
| 2 | 0.187 | 4.750 | 82.17 | 1.125 | 5.493 |
| 2 | 0.25 | 6.350 | 76.56 | 2.016 | 9.843 |
| 3 | 0.120 | 3.048 | 92.16 | 0.308 | 1.504 |
| 3 | 0.135 | 3.429 | 91.20 | 0.390 | 1.904 |
| 3 | 0.187 | 4.750 | 87.92 | 0.748 | 3.652 |
| 3 | 0.243 | 6.172 | 84.46 | 1.264 | 6.171 |
| 4 | 0.12 | 3.048 | 94.09 | 0.231 | 1.128 |
| 4 | 0.135 | 3.429 | 93.36 | 0.292 | 1.426 |
| 4 | 0.187 | 4.750 | 90.87 | 0.561 | 2.739 |
| 4 | 0.25 | 6.350 | 87.89 | 1.003 | 4.897 |
These products are available in each of 5 types:
Double-Crimp, also referred to as plain weave
Intermediate Crimp, with wires in every other crimp, the most common and most versatile type
Double & Intermediate Crimp, with all shute wires crimped and warp wires in alternate crimps
Lock Crimp, a very smooth, tight weave favored by architects
Flat Top Crimp, featuring a looser weave than the other types
Explore the Versatile Applications of Our Crimped Wire Mesh
Our crimped wire mesh stands out for its adaptability across various sectors. From robust industrial uses to refined architectural designs, discover how our mesh solutions meet diverse needs with precision and reliability. We ensure each application benefits from the unique properties of our high-quality materials.
