2500DWQ

Gain insights into the remarkable benefits of our feature and see how it can elevate your business.

Feature & Application

  • Designed for high-speed weaving of metal wire mesh.

  • Suitable for various metal materials including stainless steel, carbon steel, and galvanized wire.

  • Ideal for industrial applications such as filtration, screening, fencing, and architectural use.

  • Combines precision engineering with intelligent control systems for consistent mesh quality.

2500dwq (1)
2500dwq (2)
2500dwq (3)
2500dwq (4)
2500dwq (5)
2500dwq (6)
2500dwq (7)
ITEMSPECIFICATION
Standard Weaving Width2500 mm
Wire Diameter Range0.07 - 0.45 mm
Weaving DensityPlain weave: up to 400 meshes
Twill weave: up to 400 meshes
Dutch weave: up to 1400 meshes
Production Capacity & Rotational Speed
(Actual speed depends on weaving specifications)		10 RPM
Basic Tension20 kN/m
Mesh Lowering MethodDirect Roll Hanging
Harness TypeArch harness (2 harnesses)
Total Power14 KW
Overall Dimensions3500×4500×2150 mm
Net Weight of Product10 T
