Product Overview

Stainless Steel Twill Weave Wire Mesh for Industrial Screening is designed for industrial separation applications requiring higher strength, improved stability, and precise screening performance. The twill weave structure allows the use of heavier wire diameters while maintaining accurate openings, making it suitable for demanding screening environments where standard plain weave mesh may require additional strength.

This mesh type is widely used for industrial material classification, fine screening, and separation processes where durability and consistent performance are critical.

Key Specifications

Material: Stainless Steel 304 and Stainless Steel 316 (304L and 316L available upon request)

Weaving Type: Twill Weave

Mesh Count: 20–400 mesh, suitable for heavy screening and fine separation applications.

Wire Diameter: Approximately 0.05–0.63 mm depending on mesh specification and load requirements.

Opening Size: Approximately 0.03–1.27 mm for accurate screening and classification.

Open Area: Approximately 30%–65%, depending on mesh count and wire diameter.

Standard Width: 914 mm, 1000 mm, 1220 mm, and 1500 mm.

Standard Length: 30 m rolls (100 ft) or customized cut lengths.

Surface Finish: Bright

Standards: Manufactured according to ASTM E2016, ISO 9044, ISO 4783, or customer specifications.

Key Features

• Twill weave structure provides improved mechanical strength compared with plain weave mesh.
• Supports heavier wire diameters for increased durability and stability.
• Maintains accurate openings for consistent material separation.
• Excellent resistance to wear and deformation during continuous operation.
• Stainless steel construction provides corrosion resistance in industrial environments.
• Suitable for fine screening and precision separation applications.
• Available in customized mesh counts, wire diameters, and dimensions.
• Compatible with industrial screening equipment and OEM applications.

Typical Applications

• Industrial material screening
• Fine particle classification
• Material separation systems
• Chemical processing screening
• Food and pharmaceutical screening
• Laboratory and industrial testing
• Recycling material separation
• Custom industrial screening equipment

Customization Options

• Stainless Steel 304, 316, 304L and 316L available
• Custom mesh counts and wire diameters
• Custom roll widths and sheet sizes
• Cut-to-size panels and fabricated components
• Laser cutting and edge reinforcement
• OEM manufacturing and private labeling
• Export-standard packaging
